M6x10; bolt diameter 6mm; max fixture thickness 10mm; drill hole diameter 12mm.
M6x25; bolt diameter 6mm; max fixture thickness 25mm; drill hole diameter 12mm.
M6x40; bolt diameter 6mm; max fixture thickness 40mm; drill hole diameter 12mm.
M8x10; bolt diameter 8mm; max fixture thickness 10mm; drill hole diameter 14mm.
M8x25; bolt diameter 8mm; max fixture thickness 25mm; drill hole diameter 14mm.
M8x40; bolt diameter 8mm; max fixture thickness 40mm; drill hole diameter 14mm.
M10x10; bolt diameter 10mm; max fixture thickness 10mm; drill hole diameter 16mm.
M10x25; bolt diameter 10mm; max fixture thickness 25mm; drill hole diameter 16mm.
M10x50; bolt diameter 10mm; max fixture thickness 50mm; drill hole diameter 16mm.
M10x70; bolt diameter 10mm; max fixture thickness 70mm; drill hole diameter 16mm.
M12x10; bolt diameter 12mm; max fixture thickness 40mm; drill hole diameter 20mm.
M12x25; bolt diameter 12mm; max fixture thickness 40mm; drill hole diameter 20mm.
M12x40; bolt diameter 12mm; max fixture thickness 40mm; drill hole diameter 20mm.
M12x60; bolt diameter 12mm; max fixture thickness 40mm; drill hole diameter 20mm.
M16x15; bolt diameter 16mm; max fixture thickness 15mm; drill hole diameter 25mm.
M16x30; bolt diameter 16mm; max fixture thickness 30mm; drill hole diameter 25mm.
M16x60; bolt diameter 16mm; max fixture thickness 60mm; drill hole diameter 25mm.
